The main parameters | Parameter range |
Application areas: | Tissue homogenization, grinding, cell disruption, homogenization, material dispersion, preparation, sample mixing, shaking |
Sample processing: | It can handle 48 samples at the same time in 15 seconds, including liquid nitrogen refrigeration adapters that can be used for 12 and 24 positions |
Compatible sample volume: | 48*(0.2-0.5ML) /48*2ML /12*(5-15)ML /4*25ML /2*50ML, various specifications of grinding tubes can be customized |
Touch screen display: | Touch screen display, convenient and intuitive operation |
Storing data | Ten sets of experimental data can be stored, and animal heart, spleen, lung, kidney, bone, skin, and hair modes are set according to different experimental samples. |
Pattern cycle: | According to the set experimental parameters, it can continuously circulate among several set parameters to further reduce the interference of human factors |
Feed size | No requirement, adjust according to adapter |
Cooling function: | Yes, adjustable from -50 ℃ to room temperature |
Temperature control accuracy: | + 0.5 ℃ |
Open cover operation protection: | Electromagnetic lock |
Discharge size | ~5μm |
The number of grinding platforms (the number of grinding tanks that can be accepted) | >2 |
Fastening device with automatic center positioning | Yes |
Homogenization speed and time: | 0—70 HZ/sec, working time: 0 second to 9999 minutes, users can set by themselves; |
Range of rotation: | 1000rpm-7000rpm; |
Diameter of grinding ball: | 0.1-30mm |
Grinding ball kit material: | Alloy steel, chromium steel, zirconia, tungsten carbide, quartz sand; |
Accelerate: | Achieve greater speed in 2 seconds |
Decelerate | Reach a lower speed in 2 seconds |
Noise level: | <55db |
Grinding method | Wet grinding, dry grinding and low temperature grinding are all available |
Refrigeration: | Has the ability to upgrade to ultra-low temperature liquid nitrogen refrigeration or air refrigerator refrigeration |
Adapter material: | PTFE or alloy steel |
Fastening device: | Fastening device with automatic center positioning, safety lock when working, full protection |
Grinding kit material: | Hard steel, PTFE (Teflon) zirconia |
Opening method: | Smart start |
Dimensions | 700mm*380mm*500mm |
Weight | 75Kg |
